Products
LED Package Guide
| Chip Size | 300μm, 350μm, 400μm | 1mm or More | ||||||
| Power | Standard | High | ||||||
| Package | Mold Type | Stem Type | SMT Family | SMC Family | EDCC Family | EDC Family | SMBB Family | SLC Family |
| 3φ/5φ | 5φ/8φ | 3.5mm×2.8mm | 3.0mm×2.0mm | 1.5mm×1.85mm | 3.45mm×3.45mm | 5.2mm×5.0mm | 3.9mm×3.9mm | |
| Mold type LED. Wide lens selection |
Metal stem LED. Multiple stems & lenses available |
SMD package. Beam angle from lens ±10° available |
Compact ceramic package. Small size |
High-power compact package. Chip size, ideal for high-density mounting | Ceramic package. 2 types of lenses available |
Flagship model. Wide beam angle from ±10° & rich lens selection | Ceramic package + glass lens. Optimized for 365nm & 1750nm |
|
 |
 |
 |
 |
 |
 |
 |
 |
|
