Currently Ushio's proximity/projection exposure systems for flexible substrates have a track record of over 800 units.
Highly efficient high-resolution exposure is achieved by a projector lens that makes full use of our specially developed high-output lamp and our established reputation in optical system technology.
Easier dry cleaning
We have developed an Atmospheric Pressure Plasma Irradiation Device that combines our own reactor structure with the high-frequency power supply technology cultivated for excimer lamps.
2039
Excimer lamps/Excimer irradiation unit
Excimer VUV light is the very high-energy light generated by lamps containing noble gases or noble-gas hydride compounds.
Externally applying high-energy electrons to a sealed lamp containing a noble gas or noble gas hydride compound generates intense plasma discharge (dielectric barrier discharge). This plasma features high-energy electron content, and can be extinguished instantly. The plasma discharge instantly excites the atoms of the discharge gas (noble gas) to their excimer (Xe) state (high-energy orbital atoms form excimer excited molecules). The excimer-specific spectrum is emitted when atoms return from this excimer state to their original condition (ground state). This emission is called VUV light.
* * * *
For inquiries regarding "222 nm ultraviolet (UV-C) light antibacterial and viral inactivation device," please contact :
Sales Department, XEFL BU, Light Source Business Division
TEL: +81-3-5657-1016 / E-Mail: care222_sales@ushio.co.jp
2034
Spot UV irradiation units
The "Spot Cure Series" takes advantage of our light system technology cultivated for over 30 years, in pursuit of ease of use and environmental considerations. We offer a wide variety of lens and unit options to suit line and workpiece conditions.
2036
UV irradiance meter UIT-201
The Unimeter series was developed based on our experience and expertise as a manufacturer of optical equipment. These compact optical measuring instruments are genuinely easy-to-use from the user's standpoint. These compact UV meters are used to manage the intensity of a range of instruments, including irradiation systems, as well as UV curing, cleansing and sterilizing systems.
■ Troubleshooting is Here (requires member registration)
2036
Accumulated UV meter UIT-250
The Unimeter series was developed based on our experience and expertise as a manufacturer of optical equipment. These compact optical measuring instruments are genuinely easy-to-use from the user's standpoint. These compact UV meters are used to manage the intensity of a range of instruments, including irradiation systems, as well as UV curing, cleansing and sterilizing systems.
■ Troubleshooting is Here (requires member registration)
2036
Super-thin palm top UV irradiance meter UIT-θSeries
This wireless LED-dedicated irradiance meter is only 4.9 mm thick.
Measures optical film coatings, adhesion of precision optical parts and lenses, and UV printing processes between light source and object even in hard-to-reach locations.
■ Operating Manual and Troubleshooting are Here (requires member registration)
2036
Spectro-reflectance meter URE-50
Instantly measures spectral reflectance (from ultraviolet to near-infrared) of surfaces with up to ±R50 mm curvature as well as of flat surfaces. Despite their compact size, Ushio's unique measurement instruments support measurement of large products.
■ Operating Manual and Troubleshooting are Here (requires member registration)
2036
Spectral radiometer USR-45 Series
Ushio's irradiance meters can measure absolute values based on the photometric standard lamp established by the National Institute of Advanced Industrial Science and Technology. Measures a broad range of bands including UV, visible and infrared light, and various light sources such as steady, flashing and LED lights
■ Operating Manual and Troubleshooting are Here (requires member registration)
2033
Halogen lamp heaters
These halogen lamp heaters were developed to efficiently extract the infrared light from the halogen lamp, with more than
85% of the input power converted into heat, resulting in a very efficient energy source.
Heating by halogen lamp is rich in flexibility and controllability, with excellent characteristics no other heat source can provide. Ushio's heat processing systems are used in various industrial fields such as electronic device manufacturing processes like semiconductors and LCDs, and heating of auto parts and resin materials such as CFRP.
2033
Flash lamp annealer
Flash lamp annealing allows very short heating processes as quick as one millisecond.
UV to visible wavelength light emitted from the flash lamp can concentrate heat on a substrate (material) surface so that the thermal influence on the underlying film or substrate
can be extremely small compared with conventional heat sources.
This millisecond surface heat treatment is becoming an essential technology for future device developments such as zero diffusion of semiconductor implanted layers and thermal budget reduction.
Flash lamp heating is also used to produce reactions such as crystallization, bonding, peeling, decomposition and curing. These characteristics are effectively applied in various research and development applications such as Si wafers, SiC wafers, glass, plastic films and other flexible substrates, as well as in production (manufacturing) line applications.
We welcome requests for experimental demonstrations. Please feel free to contact us.
2037
Organs on Chip (OoC)
Organs on Chip (OoC) is receiving attention as a support tool that has the possibility to alter the course of drug development. Ushio is engaging in the development of OoC products to meet our customers’ every desire.
With our light technology and integration, we provide your desired Organs On Chip (MPS) and contribute to the development of new drugs.
2037
Light source unit for scientific use Optical Modulex
This desktop light source unit provides simple collimated IR, UV and visible light, and is ideal for spectrometry and solar cell evaluation.
All models have adjustment-free optical lamp axes for highly collimated, high-power light source experiments on the desktop.
Care222 is a new disinfecting light source that, even though not harmful to the skin or eyes of humans or animals, deactivates bacteria and viruses in the same manner as conventional ultraviolet sanitizers.
2032
Lighting for stage
We offer lamps and lighting devices for concert, stage and TV studio production applications such as the SUPERSOL® series of follow spotlights, LED-type moving lights with excellent cost performance, digital lighting systems, LED devices, and lighting consoles for optimal device control.
*This is The USHIOLIGHTING INC's product.
2032
Lighting for banquets
Follow spotlights, consisting of a wide range of moving lights from the next generation of digital lighting systems to multi-LED types, are available even in white enclosures. Our CONCERTO tracking system controls lighting direction so the light automatically tracks the bride and groom.
*This is The USHIOLIGHTING INC's product.
2032
Digital cinema projectors and related equipment
Christie projectors have continued to meet the stringent requirements of entertainment companies and post production. 2K and 4K image sizes, and 3-D video Also satisfies the high demands of the latest high frame rates. Christie projectors have been used since the early film era, and are currently in use at 36,000 sites worldwide, with over 10 million performances shown.
*This is The CHRISTIE DIGITAL SYSTEMS's product.
2032
Projectors for business and large screen applications
This product is suitable for use in medium-size indoor facilities such as large conference and multi-purpose halls. *This is The CHRISTIE DIGITAL SYSTEMS's product.
2032
3D stereoscopic projectors and related equipment
This projector and associated equipment support stereoscopic (3-D) content.
*This is The CHRISTIE DIGITAL SYSTEMS's product.
2032
Simulation projectors and related equipment
This product is suitable for simulator applications such as architecture, navigation and flight simulators. *This is The CHRISTIE DIGITAL SYSTEMS's product.
2032
Control room and video wall display products
This product is suitable for use in operation centers and control rooms.
*This is The CHRISTIE DIGITAL SYSTEMS's product.
